ET026QV02-K
| Panel Model | ET026QV02-K |
|---|---|
| Panel Brand | Eurotech |
| Descrition | a-Si TFT-LCD ,2.6 inch, 240×320 |
| Panel Type | a-Si TFT-LCD |
| ET026QV02-K Price | Request Price & Lead Time |
| System Category | LCD/OLED/EPD Flat Panel > TFT-LCD Panel |
| Series | ET026QV |
| Keywords Desc. | 2.6 inch, 240*320, 50pins, 460nits, MCU/TTL/SPI interface, TFT Module |
| Product Class | Graphic LCD Display |
| Product Tags | Color TFT-LCD, Wide Temperature LCD |
| Panel Composition | LCM |
| Resolution | 240×320 |
| Aspect Ratio | 3:4 (W:H) |
| Form Factor | Flat Rectangle |
| Active Area | 38.88 (W) × 51.84 (H) mm (A.A) |
| Outline Dimension | 46 (W) × 64 (H) mm |
| Max. Depth | 2.6 mm |
| LC Family | TN |
| Polarizer | Transmissive |
| Brightness | 460 (Typ.) |
| Contrast Ratio | 300:1 (Typ.) |
| Viewing Angle | 65/65/60/50 (L/R/U/D) |
| Viewing Direction | 6 o'clock |
| Colors Amount | 65K/262K |
| Backlight Type | WLED |
| Interface Type | CPU/RGB/SPI |
| Interface Pins | 50 Pins |
| Touch Panel | Without |
| Operating Temp. | -20 ~ 70 °C |
| Storage Temp. | -30 ~ 80 °C |
LCDs-Display.com is a specialty stocking distributor of Eurotech ET026QV02-K.
Eurotech ET026QV02-K are new & original stock available at LCDs-Display.com, same day shipping with free shiping cost.
For the Eurotech ET026QV02-K pdf datasheet or detailed specifications of the Eurotech ET026QV02-K or other Eurotech LCDs, please email us, we'll be happy to provide one.
Request a quote from Eurotech ET026QV02-K distributor at LCDs-Display.com. Email us: info@LCDs-Display.com
Eurotech ET026QV02-K are new & original stock available at LCDs-Display.com, same day shipping with free shiping cost.
For the Eurotech ET026QV02-K pdf datasheet or detailed specifications of the Eurotech ET026QV02-K or other Eurotech LCDs, please email us, we'll be happy to provide one.
Request a quote from Eurotech ET026QV02-K distributor at LCDs-Display.com. Email us: info@LCDs-Display.com
