Overview Specification

ET020QV01-K

Panel Model ET020QV01-K
Panel Brand Eurotech
Descrition a-Si TFT-LCD ,2.0 inch, 240×320
Panel Type a-Si TFT-LCD
ET020QV01-K Price Request Price & Lead Time
System CategoryLCD/OLED/EPD Flat Panel > TFT-LCD Panel
SeriesET020QV
Keywords Desc.2.0 inch, 240*320, 45pins, 250nits, MCU interface, TFT Module
Product ClassGraphic LCD Display
Product TagsColor TFT-LCD, Wide Temperature LCD, Transflective LCD, Sunlight Readable LCD
Panel CompositionLCM
Resolution240×320
Aspect Ratio3:4 (W:H)
Form FactorFlat Rectangle
Active Area30.6 (W) × 40.8 (H) mm (A.A)
Outline Dimension35.8 (W) × 52.1 (H) mm
Max. Depth2.65 mm
LC FamilyVA Family
PolarizerTransflective
Brightness250 (Typ.)
Contrast Ratio800:1 (Typ.)
Viewing Angle80/80/80/80 (L/R/U/D)
Viewing DirectionSymmetry
Colors Amount65K/262K
Backlight TypeWLED
Interface TypeCPU/RGB/SPI
Interface Pins45 Pins
Touch PanelWithout
Operating Temp.-20 ~ 70 °C
Storage Temp.-30 ~ 80 °C
ET020QV01-KET020QV01-KET020QV01-KET020QV01-K
LCDs-Display.com is a specialty stocking distributor of Eurotech ET020QV01-K.
Eurotech ET020QV01-K are new & original stock available at LCDs-Display.com, same day shipping with free shiping cost.
For the Eurotech ET020QV01-K pdf datasheet or detailed specifications of the Eurotech ET020QV01-K or other Eurotech LCDs, please email us, we'll be happy to provide one.
Request a quote from Eurotech ET020QV01-K distributor at LCDs-Display.com. Email us: info@LCDs-Display.com
